SCHURTER's SHF and SHT Fuse Series and FUS Fuseholder Series

SCHURTER’s high performance SHF and SHT fuses provide higher voltage, overcurrent, and short circuit protection in a universally accepted compact package size 6.3x32 mm. The SHF and SHT fuses offer 16 rated currents from 0.5A to 32A up to 500 VAC/VDC.

  • Quick-Acting…Primary protection up to 500 VAC/VDC. Breaking capacity up to 50kA VAC and 20kA VDC.
  • Time-Lag…Primary protection up to 500 VAC and 400 VDC. Breaking capacity up to 10kA VAC and 20kA VDC.
  • Applications for Fuses: 3-phase systems, Photovoltaic inverter to grid DC to AC or DC to DC, HVAC, Lighting systems, server farms and more.
  • The FUS series shock-safe, snap-in panel mount fuseholder is designed for robust applications and is IP67 weatherproof rated. The FUS is rated 16 A @ 500 VAC (IEC) and up to 32 A @ 600 VAC /VDC (UL/CSA). The fuseholder accepts 5x20 mm or 6.3 x 32 mm fuses.
  • Applications: Equipment exposed to outdoor weather, or oil and chemical, marine, medical, food processing, laboratory and mining environments.
View
Show products manufactured by Schurter
Authorized Distributor
Visit Website
Information
Product Range Live Chat Tech Support Datasheet
Product Guides

93 PRODUCT RESULTS FOR ""

Filter Results

93 Products

    8020.5072
    Data Sheet
    8020.5072 Schurter
    SHF 6.3x32, 2.5 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    VIEW PRODUCT
    In Stock: 1350
    Can Ship immediately
    MANUFACTURER STOCK 550
    can ship 11/25/24
    30
    $0.6389
    250
    $0.5415
    1,000
    $0.5037
    2,500
    $0.4773
    5,000
    $0.4652
    8020.5071
    Data Sheet
    8020.5071 Schurter
    SHF 6.3x32, 2 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    VIEW PRODUCT
    In Stock: 950
    Can Ship immediately
    30
    $0.6389
    250
    $0.5415
    1,000
    $0.5037
    2,500
    $0.4773
    5,000
    $0.4652
    8020.5074
    Data Sheet
    8020.5074 Schurter
    SHF 6.3x32, 4 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    VIEW PRODUCT
    In Stock: 330
    Can Ship immediately
    30
    $0.6389
    250
    $0.5415
    1,000
    $0.5037
    2,500
    $0.4773
    5,000
    $0.4652
    8020.5073
    Data Sheet
    8020.5073 Schurter
    SHF 6.3x32, 3.15 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    VIEW PRODUCT
    In Stock: 20
    Can Ship immediately
    1
    $0.6248
    50
    $0.5680
    250
    $0.4502
    1,000
    $0.4089
    2,500
    $0.4028
    8020.5071.PT
    Data Sheet
    8020.5071.PT Schurter
    SHT 6.3x32 Pigtail, 2 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse, 6.3x32
    VIEW PRODUCT
    In Stock: 1
    Can Ship immediately
    1
    $0.5943
    100
    $0.5403
    300
    $0.5203
    1,000
    $0.4946
    2,500
    $0.4872
    8020.5075
    Data Sheet
    8020.5075 Schurter
    SHF 6.3x32, 5 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse
    VIEW PRODUCT
    MANUFACTURER STOCK 2010
    can ship 11/25/24
    30
    $0.6712
    250
    $0.5629
    1,000
    $0.5209
    2,500
    $0.4915
    5,000
    $0.4781
    8020.5070.PT
    Data Sheet
    8020.5070.PT Schurter
    SHT 6.3x32 Pigtail, 1.6 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse, 6.3x32
    VIEW PRODUCT
    20 Weeks
    100
    $0.819
    300
    $0.666
    1,000
    $0.636
    2,500
    $0.584
    5,000
    $0.575
    8020.5072.PT
    Data Sheet
    8020.5072.PT Schurter
    SHT 6.3x32 Pigtail, 2.5 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse, 6.3x32
    VIEW PRODUCT
    20 Weeks
    100
    $0.819
    300
    $0.666
    1,000
    $0.636
    2,500
    $0.584
    5,000
    $0.575
    8020.5073.PT
    Data Sheet
    8020.5073.PT Schurter
    SHT 6.3x32 Pigtail, 3.15 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse, 6.3x32
    VIEW PRODUCT
    20 Weeks
    100
    $0.819
    300
    $0.666
    1,000
    $0.636
    2,500
    $0.584
    5,000
    $0.575
    8020.5074.PT
    Data Sheet
    8020.5074.PT Schurter
    SHT 6.3x32 Pigtail, 4 A, 500 VAC, Quick-Acting F, Non-Resettable Fuse, 6.3x32
    VIEW PRODUCT
    20 Weeks
    100
    $0.819
    300
    $0.666
    1,000
    $0.636
    2,500
    $0.584
    5,000
    $0.575
