CPN1 by aim-cambridge / cinch connectivity solutions
DATA SHEET

CPN1

AIM-Cambridge / Cinch Connectivity Solutions

N-CRIMP PLUG-RG58 .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
AIM-Cambridge / Cinch Connectivity Solutions
Part No:
CPN1
RoHS:
Yes
HTS:
8536694010
COO:
TW
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Type N
Impedance:
50 Ohm
Operating Frequency:
0 to 11 Hz to GHz
Gender:
PL
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
RG58 Cable
Termination Method:
Crimp
Operating Temperature:
-65 to 165 °C
Dimension:
36.83 x 19.3 mm
The AIM-CAMBRIDGE / CINCH CONNECTIVITY SOLUTIONS CPN1 is a premium quality N-type connector designed for frequencies ranging from 0Hz to 11GHz. It features a 50Ohm impedance, crimp style mounting, and gold plated contacts for superior signal transmission. Perfect for high-frequency applications requiring reliable connectivity, the CPN1 ensures maximum performance and durability.
Search Keywords:
CPN1
IN STOCK: 50
Can Ship immediately
On Order:
100   can ship 11/25/24
Minimum Order:
5
Factory Lead-Time
20 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$7.64
$38.200
50
$5.72
$286.000
100
$5.05
$505.000
300
$4.78
$1,434.000
500
$4.46
$2,230.000
1,000
$4.17
$4,170.000
2,500
$4.11
$10,275.000
5,000 +
$4.05
$20,250.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
