AZ9871-1C-12DET by american zettler
DATA SHEET

AZ9871-1C-12DET

American Zettler

30AMP Micro Automotive Relay 12VDC coil SPDT .. see full description

RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ9871-1C-12DET
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Box
Contact Form:
SPDT (1 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
30A (NO) / 25A (NC)
Coil Voltage:
12 VDC
Coil Current:
47.2 mA
Coil Resistance:
254 Ohm
Contact Material:
Silver Tin Oxide
Must Operate Voltage:
6.9 VDC
Must Release Voltage:
1.5 VDC
Operate Time:
3 ms
Seal:
Sealed
Mounting:
Through Hole
Termination Style:
PC Pin
Dimension:
13.2 x 12.3 x 10.2 mm
Operating Temperature:
-40 to 105 °C
Packaging:
N/A
The AMERICAN ZETTLER part AZ9871-1C-12DET is a highly durable and reliable 30AMP Micro Automotive Relay. It features a 12VDC coil, making it ideal for use in various automotive applications. This single pole, double throw (SPDT) relay is designed to handle high currents, offering exceptional performance and longevity. Whether you need to control lights, motors, or other automotive electrical systems, this AZ9871-1C-12DET relay is the perfect choice. Trust in its quality construction and efficient functionality for seamless operation in your vehicle.
Search Keywords:
AZ98711C12DET
IN STOCK: 2,192
Can Ship immediately
Minimum Order:
100
Multiple:
100
Factory Lead-Time
8 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
100
$1.122
$112.200
300
$0.987
$296.100
500
$0.925
$462.500
1,000
$0.860
$860.000
2,500
$0.840
$2,100.000
5,000
$0.825
$4,125.000
7,500
$0.817
$6,127.500
10,000 +
$0.808
$8,080.000
