31-315-RFX by amphenol rf
DATA SHEET

31-315-RFX

Amphenol RF

RF Connector - BNC Straight Crimp Plug for RG-174, RG-188, RG-316 - 50 Ohm - Maximum Frequency 4 GHz - Brass. .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
31-315-RFX
Alias/AKA:
031-315-RFX
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
PL
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Crimp
Operating Temperature:
N/A
Dimension:
30.2 x 14.5 mm
The 31-315-RFX is a BNC straight Crimp Plug with gold-plated brass contacts, nickel-plated brass body and a Delrin insulator. The BNC is a bayonet style connector allowing for quick connect and disconnect with a positive locking mechanism. Mating is achieved with just a quarter turn of the coupling nut. Designed to accommodate a large variety of RG and industry standard cables. This 50R miniature BNC connector is designed for M17/93-RG178, RG-178, RG-178A, RG-178B, RG-196 and RG-196A cable.
Search Keywords:
31315RFX
IN STOCK: 1,789
Can Ship immediately
Manufacturer Stock:
16,702   can ship 11/29/24
Minimum Order:
10
Factory Lead-Time
11 Weeks can ship 1/30/25
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$2.97
$29.700
50
$1.67
$83.500
300
$1.64
$492.000
500
$1.56
$780.000
1,000
$1.54
$1,540.000
2,500
$1.51
$3,775.000
5,000
$1.49
$7,450.000
7,500 +
$1.47
$11,025.000
Please Note: Item may be subject to tariff fee if shipping within the United States
