AR-16-HZL-TT by assmann wsw components
DATA SHEET

AR-16-HZL-TT

Assmann WSW Components

Conn IC Socket SKT 16 POS 2.54mm Solder ST Thru-Hole .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Assmann WSW Components
Part No:
AR-16-HZL-TT
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
6960
Type:
IC Socket
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Pitch:
2.54 mm
Number of Contacts:
16
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3 A
Operating Temperature:
-55 to 125 °C
The ASSMANN WSW COMPONENTS AR-16-HZL-TT is a high-quality IC socket with 16 positions, designed for convenient and secure connection of integrated circuits. This socket features a 2.54mm pitch and is designed for soldering onto a circuit board using through-hole mounting. Perfect for use in a wide range of electronic applications, this socket provides a reliable and durable connection for your IC components.
Search Keywords:
AR16HZLTT
IN STOCK: 1,413
Can Ship immediately
On Order:
4,988   can ship 12/19/24
Minimum Order:
50
Factory Lead-Time
20 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
50
$0.7481
$37.405
250
$0.6274
$156.850
1,000
$0.5806
$580.600
2,500
$0.5479
$1,369.750
6,960
$0.5187
$3,610.152
13,920
$0.5109
$7,111.728
20,880
$0.5032
$10,506.816
27,840 +
$0.4957
$13,800.288
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
