DATA SHEET

RA2425-D06T

Carlo Gavazzi

SSR ZS 240V 25A 3-32VDC T .. see full description

RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Discontinued & Replaced
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Carlo Gavazzi
Part No:
RA2425-D06T
RoHS:
Yes
HTS:
8535908085
COO:
MT
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
280(RMS) V
Maximum Output Current:
25(RMS) A
Output Device:
Triac
Input Type:
DC
Input Voltage:
32 V
Mounting:
Screw
Circuit Arrangement:
N/A
Dimension:
45.5 x 58.2 x 29 mm
Life Cycle:
Discontinued & Replaced
The RA2425-D06 is a 1-phase Solid State Relay with SPST-NO contact, NORYL GFN 1 black housing and nickel-plated aluminium base plate. This panel mount relay features zero crossing switching mode and screw terminals. The zero switching relay with ant parallel thyristor output is the most widely used industrial SSR due to its multiple application possibilities. The relay can be used for resistive, inductive and capacitive loads. The zero switching relay switches ON when the sine curve just crosses zero and switches OFF when the current crosses zero. Direct copper bonding technology 230VACrms Operational voltage 650Vp Blocking voltage ≤1.6Vrms On-state voltage drop 1.5kΩ Input impedance ≤1/2cycle Pick-up/drop-out response time -20 to 70°C Operating temperature range Applications Industrial
Search Keywords:
RA2425D06T
  This product is not in stock and cannot be back-ordered
RECOMMENDED REPLACEMENT
RA2425-D06
RA2425-D06
VIEW PRODUCT
