7803K12 by cutler-hammer / eaton
DATA SHEET

7803K12

Cutler-Hammer / Eaton

Switch Toggle ON OFF ON DPDT Round Lever Solder Lug 20A 250VAC 745.7VA Panel Mount with Threads .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Cutler-Hammer / Eaton
Part No:
7803K12
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:
1
Package Type:
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Operating Temperature:
-17.8 to 65.6 °C
This CUTLER HAMMER/EATON part 7803K12 is a versatile and durable toggle switch that features a Double Pole Double Throw (DPDT) configuration with an ON OFF ON function. The switch has a round lever design, making it easy to operate, and comes equipped with solder lugs for secure and reliable connections. With a high current rating of 20A at 250VAC and 745.7VA, this switch is suitable for a wide range of applications. The panel mount design with threads ensures easy installation and secure mounting.
Search Keywords:
7803K12
IN STOCK: 184
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
12 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$9.28
$46.400
25
$8.41
$210.250
50
$8.03
$401.500
100
$7.80
$780.000
250
$7.37
$1,842.500
500
$7.17
$3,585.000
1,000 +
$7.07
$7,070.000
