XTD4C3A by cutler-hammer / eaton
DATA SHEET

XTD4C3A

Cutler-Hammer / Eaton

Switch Toggle ON None ON DPDT Round Lever Solder Lug 20A 277VAC 28VDC 1118.55VA Panel Mount with Threads Bag .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Cutler-Hammer / Eaton
Part No:
XTD4C3A
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
1118.55 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Solder
Operating Temperature:
0 to 65 °C
Life Cycle:
Discontinued
The CUTLER HAMMER/EATON XTD4C3A is a high-quality toggle switch designed for a variety of applications. This switch features a DPDT (Double Pole Double Throw) configuration, allowing for versatile operation. The toggle lever has a round shape and is easy to handle. It is solder lug terminations, providing secure connections. With a maximum operating current of 20A at 277VAC and 28VDC, this switch offers reliable power control. The XTD4C3A also has a maximum VA (volt-ampere) rating of 1118.55, ensuring efficient performance. Designed for panel mounting with threads and conveniently packaged in a bag, this switch is easy to install and store.
Search Keywords:
XTD4C3A
  This product is discontinued, but still in stock
IN STOCK: 320
Ships today, if you order in
Minimum Order:
5
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$7.00
$35.000
25
$5.87
$146.750
100
$5.43
$543.000
250
$5.20
$1,300.000
500
$4.99
$2,495.000
1,000
$4.85
$4,850.000
2,500
$4.73
$11,825.000
5,000 +
$4.66
$23,300.000
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
