100DP1T2B4M6QE by e-switch
DATA SHEET

100DP1T2B4M6QE

E-Switch

Toggle Switch - DPDT - On-None-On - 120VAC/28VDC - 5A - Silver Plated Contacts - Right Angle PC Mount - 1/4" Dia x .280" No Thread Bushing - No Hardware

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
100DP1T2B4M6QE
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
54
Package Type:
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever
Mounting:
PC Mount with Bracket
Thread Size:
N/R
Body Orientation:
Right Angle
Terminal Type:
PC Pins
Dimension:
12.7 x 30.97 x 11.43 mm
Operating Temperature:
-30 to 85 °C
Toggle Switch - DPDT - On-None-On - 120VAC/28VDC - 5A - Silver Plated Contacts - Right Angle PC Mount - 1/4" Dia x .280" No Thread Bushing - No Hardware
Search Keywords:
100DP1T2B4M6QE
IN STOCK: 92
Ships today, if you order in
Minimum Order:
54
Multiple:
54
Factory Lead-Time
12 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
54
$3.780
$204.120
108
$3.564
$384.912
270
$3.389
$915.030
540
$3.079
$1,662.660
1,026
$2.941
$3,017.466
2,538
$2.912
$7,390.656
5,022
$2.883
$14,478.426
7,506 +
$2.854
$21,422.124
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
