DATA SHEET

624H

ebm-papst

DC Fan Axial Ball Bearing 24V 18V to 28V 27.1CFM 39dB (60 X 60 X 25.4mm) Low Noise .. see full description

RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
ebm-papst
Part No:
624H
RoHS:
Yes
HTS:
8414599080
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Category:
DC Fan
Dimension:
60 x 60 x 25.4 mm
Voltage Rating:
24 V
Power Rating:
2.4 W
Maximum Airflow:
27.1 CFM
Noise Level:
39 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-20 to 70 °C
The 620 series DC Axial Fan is suitable for high air performance with moderate pressure build-up. The flow of air through the fan blades is parallel to the rotation axis. They are extremely flat and space-saving integrated motor. Every single type of fan can be optimally integrated in the respective device concept. The highly economical brushless motor technology of these fans provides unique variety of intelligent innovations. The DC fans have electronically commutated drives with electronic protection against reverse polarity. The DC fans with sleeve and ball bearings are powered by class E insulated motors. Power (Watts) 2.40W RPM 6850 RPM Termination 2 Wire Leads Operating Temperature -4 ~ 158°F (-20 ~ 70°C) Electronic protection against reverse polarity Exhaust over struts direction of air flow Clockwise direction of rotation Connection via 22AWG single wires Very low noise motor Speed signal Alarm with speed limit External temperature sensor Internal temperature sensor PWM control input Analogue control input Moisture protection
Search Keywords:
624H
IN STOCK: 657
Ships today, if you order in
Manufacturer Stock:
339   can ship 11/18/24
Factory Lead-Time
13 Weeks can ship 2/5/25
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$36.28
$36.280
5
$34.35
$171.750
10
$19.32
$193.200
25
$19.03
$475.750
50
$18.74
$937.000
100
$18.46
$1,846.000
250 +
$18.18
$4,545.000
Tools/3D Models
