56DP30-01-1-AJN by grayhill
DATA SHEET

56DP30-01-1-AJN

Grayhill

Switch Rotary SP Flatted Shaft PC Pins 0.2A 115VAC 30VDC .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
56DP30-01-1-AJN
RoHS:
Yes
HTS:
8536509020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Number of Positions:
N/A
Pole Throw Configuration:
SP12T
Actuator Length:
9.53 mm
Dimension:
12.7 x 12.7 x 25.46 mm
Actuator Style/Diameter:
Flatted Shaft/3.18
Mounting:
Panel Mount/Through Hole
Body Orientation:
Straight
Terminal Type:
PC Pins
Angle of Throw:
30 °
Contact Rating @ Voltage:
0.2 A
The GRAYHILL part 56DP30-01-1-AJN is a reliable and versatile rotary switch designed for various applications. It features a single-pole configuration with a flatted shaft and PC pins for easy installation. With a maximum current rating of 0.2A, it is suitable for low-power electrical systems. This switch can handle up to 115VAC or 30VDC voltage, making it compatible with a wide range of devices. Trust in GRAYHILL's reputation for quality and durability when using the 56DP30-01-1-AJN rotary switch in your next project.
Search Keywords:
56DP30011AJN
IN STOCK: 270
Ships today, if you order in
Factory Lead-Time
9 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$22.32
$22.320
10
$15.08
$150.800
25
$14.19
$354.750
50
$13.01
$650.500
100
$12.88
$1,288.000
250
$12.76
$3,190.000
500 +
$12.63
$6,315.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
