DATA SHEET

71BDF30-03PAJS

Grayhill

Switch Rotary SP Flatted Shaft PC Pins 0.3A 115VAC 30VDC

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
71BDF30-03PAJS
Alias/AKA:
71BDF30-03-1-AJS
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Number of Positions:
N/A
Pole Throw Configuration:
SP
Actuator Length:
9.53 mm
Dimension:
22.23mm x 47.85mm x 18.08 mm
Actuator Style/Diameter:
Flatted Shaft/6.36
Mounting:
Panel Mount/Through Hole
Body Orientation:
Right Angle
Terminal Type:
PC Pins
Angle of Throw:
30 °
Contact Rating @ Voltage:
0.3@115VAC A
Switch Rotary SP Flatted Shaft PC Pins 0.3A 115VAC 30VDC
Search Keywords:
71BDF3003PAJS
IN STOCK: 0
On Order:
25   can ship 1/27/25
MOQ for out of Stock Qty:
7
Factory Lead-Time
9 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$74.44
$74.440
5
$50.87
$254.350
7
$46.54
$325.780
13
$46.07
$598.910
19
$44.65
$848.350
25 +
$44.20
$1,105.000
