M3786/4-3866GL by grayhill
DATA SHEET

M3786/4-3866GL

Grayhill

Switch Rotary SP3T 3 Flatted Shaft Solder Lug 5A 115VAC 28VDC .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
M3786/4-3866GL
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack:
10
Package Type:
Number of Positions:
3
Pole Throw Configuration:
SP3T
Actuator Length:
11.1 mm
Dimension:
29.51 x 31.07 x 48.24 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
45 °
Contact Rating @ Voltage:
5@115VAC A
The GRAYHILL M3786/4-3866GL is a high-quality rotary switch designed for a single pole triple throw (SP3T) configuration. It features a durable construction with a 3-flatted shaft that ensures easy and secure installation. The switch is suitable for various applications and can handle a maximum current of 5A and voltage of 115VAC or 28VDC. With solder lug terminals, it allows for convenient and reliable soldering connections. Whether you need to switch between different circuits or control different functions, the GRAYHILL M3786/4-3866GL provides reliable performance and versatility.
Search Keywords:
M378643866GL
IN STOCK: 16
Can Ship immediately
MOQ for out of Stock Qty:
3
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$127.22
$127.220
3
$116.97
$350.910
5
$115.80
$579.000
8
$113.37
$906.960
10 +
$111.43
$1,114.300
DOWNLOADS
PDF Datasheet
Request Free CAD Models
