11CX12 by Honeywell
DATA SHEET

11CX12

Honeywell

MICRO SWITCH™ Hazardous Location Switches: CX Series, Epoxy-Coated Aluminum Short Housing, Side Rotary, Maintained, (2) Single Pole Double Throw (SPDT) Basic Switches, 15 A 125, 250, or 480 Vac, NEMA 1, 3, 4, 4X, 6, 6P, 13, and IP66 Seal Rating, Operating Temperature: -25 °C to 85 °C [-13 °F to 185 °F], (2) 3/4 in - 14 NPT Conduit Termination, NEMA 7: Class I, Div. 1 & 2, Groups C & D; NEMA 9: Class II, Div. 1 & 2, Groups E, F, & G, Agency Approvals: UL, CSA, Internal Ground Screw .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
11CX12
RoHS:
Yes
HTS:
85365099
COO:
MX
ECCN:
EAR99
Type:
Explosion Proof
Actuator Style:
Side Rotary
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Operating Force:
N/A
Dimension:
101.6 x 126.3 x 101.6 mm
Maximum Current Rating:
15@480VAC@(CSA/UL) A
Terminal Type:
Conduit
NEMA Standard as Enclosure Rating:
1, 3, 4, 4X, 6, 6P, 7, 9, 13
Body Orientation:
Right Angle
The HONEYWELL part 11CX12 is a MICRO SWITCH„¢ Hazardous Location Switch designed for use in environments with potentially explosive gases or dust. It features an epoxy-coated aluminum short housing and a side rotary actuator for easy operation. The switch has a maintained action and includes two single pole double throw (SPDT) basic switches.The switch can handle a current of 15 A at 125, 250, or 480 Vac and has a NEMA 1, 3, 4, 4X, 6, 6P, 13, and IP66 seal rating, ensuring protection against dust, water, and corrosion. It can operate in temperatures ranging from -25 °C to 85 °C (-13 °F to 185 °F).The switch features two 3/4 inch - 14 NPT conduit terminations for easy installation. It is approved for use in hazardous locations according to NEMA 7 (Class I, Div. 1 & 2, Groups C & D) and NEMA 9 (Class II, Div. 1 & 2, Groups E, F, & G) standards. The switch is UL and CSA approved and also includes an internal ground screw for added safety.
Product Highlights:
  • Sealing - applicable portions of NEMA 1, 3, 4, 4X, 6, 6P, 7, 9, and 13
  • Watertight and dust-tight for outdoor use
  • 4 mA to 20 mA analog output available
  • UL Listed, file #E14274
  • Analog UL file #E68247
  • CSA Certified, file #LR57324
  • Rugged, cast aluminum housing
  • Pretravel, overtravel, and actuating sequence can be field adjusted without tools (all basics individually)
  • Rotary types convert in seconds to clockwise, counter-clockwise, or both-way operation
Potential Applications:
  • Control valves and actuators
  • Petro-chemical plants
  • Grain handling
  • Waste treatment
  • Hazardous waste handing
  • Power generating
  • Paint facilities
Search Keywords:
11CX12
IN STOCK: 0
On Order:
12   can ship 7/31/24
Factory Lead-Time
19 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$869.13
$869.130
3
$864.79
$2,594.370
5
$860.46
$4,302.300
10 +
$856.16
$8,561.600
