11SM3-T by honeywell
DATA SHEET

11SM3-T

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: SM Series, Single Pole Double Throw (SPDT), 5 A at 250 Vac, Pin Plunger Actuator, Solder Termination .. see full description

  • RoHS Compliant
  • Box Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
11SM3-T
RoHS:
Yes
HTS:
8536509065
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:
100
Package Type:
Box
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Pin Plunger
Contact Rating @ Voltage:
5 A
Maximum Movement Differential:
0.1 mm
Operating Force:
1.39 N
Termination Style:
Solder
Dimension:
19.8mm x 6.4mm x 11.18 mm
Body Orientation:
Straight
IP Rating:
N/A

Snap Action Switches, also known as micro switches are a kind of momentary contact switch. The SM series subminiature basic micro switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other and are therefore mostly used in aerospace, instrumentation, timing devices, vending machines, computer/business equipment, test instruments, HVAC equipment's, office equipment's, manually operated devices, valves.

11SM3-T Snap Action Switch from Honeywell is a sub-miniature basic switch. It comes with an operating force of 1.39 N, an operating temperature ranging between -54 to 121 °C and has a mechanical life up to 10,000,000 cycles at 95%. This switch is small size and light weight with ample electrical capacity.

Product Highlights:
  • Long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Ampere rating: 5 A
  • Light weight
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)
Potential Applications:
  • Aerospace
  • Instrumentation
  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
