12TL1-31M

MICRO SWITCH™ Toggle Switches: TL Series, Double Pole Double Throw (DPDT) 2 Position, Half Throw (On - On), Solder Turret Terminals, Locking Lever (Locked Out Of And Into Extreme Position, Opposite Keyway), Military Part Number MS27738-33M .. see full description

RoHS Compliant

Packaging

Accessories

Request Programming Quote

Discontinued

Certificate of Compliance Guarantee

SPECS
FULL DESCRIPTION

Product Attribute

Attribute Value Select Attribute

Products found: 0Show Similar

Supplier:

Honeywell

Part No:

12TL1-31M

Alias/AKA:

MS27738-33M

RoHS:

Yes

HTS:

8536508099

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

Package Type:

Pole Throw Configuration:

2P2T (DPDT)

Switch Configuration:

On None On

Contact Rating @ Voltage:

745.7@(CSA/UL) A

Actuator Style:

Locking Lever

Mounting:

Panel Mount with Threads

Thread Size:

15/32-32

Body Orientation:

Straight

Terminal Type:

Solder

Dimension:

34.04 x 23.11 x 75.95 mm

Operating Temperature:

-65 to 72 °C

Life Cycle:

Discontinued

The HONEYWELL 12TL1-31M is a MICRO SWITCHâ„¢ toggle switch from the TL Series. It features a double pole double throw (DPDT) configuration with 2 positions and a half throw (On - On) functionality. The switch is equipped with solder turret terminals for secure and reliable connections. It also comes with a locking lever that can be locked out of and into extreme positions, opposite the keyway. This switch is designed to meet military standards and its military part number is MS27738-33M.
