1TL1-2 by honeywell
DATA SHEET

1TL1-2

Honeywell

TL Series Single Pole Toggle Switch - Off-On operation - 15A - Screw terminals - Mil PN: MS24523-22 .. see full description

RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1TL1-2
Alias/AKA:
MS24523-22
RoHS:
Yes
HTS:
8536509065
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Box
Pole Throw Configuration:
1P1T (SPST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
745.7@(CSA/UL) A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
28.4mm x 15.7mm x 63.47mm
Operating Temperature:
-65 to 71 °C
The Honeywell TL Series Military grade toggle switches with long operating life.Qualified to MIL-DTL-3950, Temp operating: -65 to 71°C, Contacts: Silver alloy or gold plated, Amp Rating: Up to 20A, Non-Illuminated
Product Highlights:
  • Qualified to MIL-DTL-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85°F to +160°F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
Potential Applications:
  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation
Search Keywords:
1TL12
IN STOCK: 1,869
Ships today, if you order in
On Order:
3,000   can ship 2/17/25
Factory Lead-Time
18 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$29.51
$29.510
5
$25.19
$125.950
10
$22.19
$221.900
25
$20.76
$519.000
50
$20.45
$1,022.500
100
$20.14
$2,014.000
300 +
$19.84
$5,952.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
