1TL1-3D by honeywell
DATA SHEET

1TL1-3D

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, Single Pole Double Throw (SPDT) 2 Position (On - On), Screw Terminals, Locking Lever (Locked Out Of Center Position), Military Part Number MS24658-23D .. see full description

  • RoHS Compliant
  • Box Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1TL1-3D
Alias/AKA:
MS24658-23D
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
Package Type:
Box
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
20@28VDC A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
28.4 x 15.7 x 72.9 mm
Operating Temperature:
-65 to 72 °C

Toggle Switches are manually actuated by means of a projecting lever, such as mechanical lever, handle or a rocking mechanism. These electrical switches are available in many different styles and sizes. They are generally used in military and commercial aviation, agricultural machinery, and process control applications.

1TL1-3D Honeywell Switch features environment-proof sealing and has pull-to-unlock levers. The switching chambers are completely sealed, while its step-design case offers an extra space between the terminals to help prevent shorting. With a temperature range between -85°F to +160°F, Honeywell 1TL1-3D enables both maintained and momentary toggle action. This On On SPDT Switch is used in industrial machinery and equipment, construction equipment, test instruments and medical instrumentation.

Product Highlights:
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
  • Temperature range: -85°F to +160°F
  • Qualified to MIL-DTL-3950
  • Environment-proof sealing
  • 1, 2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Completely sealed switching chamber
Potential Applications:
  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation
Search Keywords:
1TL13D
