1TL1-7E

The Honeywell 1TL1-7E Toggle Switch comes with high-strength, temperature resistant, non-tracking case material and silver cadmium oxide contacts. The TL series toggle switches are qualified to meet military specifications and are UL recognized, CSA certified and CE approved for global use. Toggle Switches are manually actuated by means of a projecting lever, such as mechanical lever, handle or a rocking mechanism. These electrical switches are available in many different styles and sizes. They are generally used in military and commercial aviation, agricultural machinery, and process control applications.

The 1TL1-7E Honeywell Toggle Switch features environment-proof sealing and has pull-to-unlock lever. The switching chamber is completely sealed, while its step-design case offers an extra space between the terminals to prevent short circuit. This Toggle Switch allows both maintained and momentary toggle action. This SPDT On-Off-On Toggle Switch is also used in industrial machinery and equipment, construction equipment, test instruments and medical instrumentation.

Product Highlights:

Step-design case provides added space between terminals to help prevent shorting
UL recognized, CSA certified
CE approved
Qualified to MIL-DTL-3950
Environment-proof sealing
1, 2, and 4 pole circuitry
Standard and pull-to-unlock levers
2 and 3 position, maintained and momentary toggle action
Completely sealed switching chamber
