DATA SHEET

23AC81

Honeywell

MICRO SWITCH™ Basic Switches: AC Series, Door Switch, Single Pole Double Throw (SPDT), 5 A at 250 Vac, Rod Actuator, Silver Contacts, Quick Connect Termination .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
23AC81
RoHS:
Yes
HTS:
85365000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Type:
Door Interlock
Actuator Style:
Rod
Pole Throw Configuration:
SPDT
Maximum Current Rating:
5@277VAC A
Terminal Type:
Quick Connect
Operating Temperature:
-18 to 82 °C
IP Rating:
N/A
Dimension:
50.01 x 13.21 x 45.97 mm
Switch Configuration:
N.O./N.C.
Body Orientation:
Straight

The 23AC81 Safety Interlock Switch from Honeywell is designed for precision on/off application needs. This Honeywell Switch is available with a choice of momentary, maintained or pull-to-cheat actuation to offer design flexibility. Safety Interlock Switches are designed for mounting on a door or a cover, so that when the door or other part is opened, they open automatically. They prevent the gear shift lever from moving until the brake is applied.

When the service door, panel or drawer is opened, it cuts down the power by itself automatically. The current rating of this Interlock Safety Switch ranges from 5 A to 25 A. They are generally used in vending machines, office equipment, computer and business equipment, test instruments, communications equipment, and HVAC equipment, among others.

Product Highlights:
  • Current rating ranges from 5 A to 25 A
  • Automatically cuts power when service door or drawer is opened
  • Choice of momentary, maintained or pull-to-cheat actuation
  • Choice of termination
  • Versatile mounting bracket for side or end mounting
  • Available with one or two SPDT switches
  • UL recognized versions available
Potential Applications:
  • Appliances
  • Vending machines
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
Search Keywords:
23AC81
IN STOCK: 3,891
Ships today, if you order in
Factory Lead-Time
22 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$120.89
$120.890
5
$111.87
$559.350
10
$108.62
$1,086.200
25
$102.67
$2,566.750
50
$99.93
$4,996.500
200
$96.09
$19,218.000
400 +
$94.65
$37,860.000
