2TL1-1 by honeywell
DATA SHEET

2TL1-1

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, Double Pole Double Throw (DPDT) 3 Position (On - Off - On), Screw Terminals, Standard Lever, Military Part Number MS24524-21 .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2TL1-1
Alias/AKA:
MS24524-21
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On Off On
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.5mm x 22.6mm x 63.47mm
Operating Temperature:
-65 to 71 °C
The HONEYWELL part 2TL1-1 is a high-quality MICRO SWITCH„¢ Toggle Switch designed for various applications. It belongs to the TL Series and features a Double Pole Double Throw (DPDT) configuration with 3 positions €“ On, Off, and On. The switch is equipped with screw terminals for easy installation and a standard lever for smooth operation. It also meets military specifications and has the military part number MS24524-21. This toggle switch offers reliable performance and durability, making it an ideal choice for military, aerospace, and industrial applications.
Product Highlights:
  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
Potential Applications:
  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation
Search Keywords:
2TL11
IN STOCK: 226
Can Ship immediately
Factory Lead-Time
5 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$42.57
$42.570
5
$37.98
$189.900
10
$37.41
$374.100
30
$35.78
$1,073.400
50
$33.82
$1,691.000
100
$33.31
$3,331.000
250 +
$32.49
$8,122.500
Suppliers Standard Package
