DATA SHEET

2TL1-21

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, Double Pole Single Throw (DPST) 2 Position, Half Throw (Off - On), Screw Terminals, Standard Lever, Military Part Number MS24524-24 .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2TL1-21
Alias/AKA:
MS24524-24
RoHS:
Yes
HTS:
8536509065
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Pole Throw Configuration:
2P1T (DPST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.5mm x 22.6mm x 63.47mm
Operating Temperature:
-65 to 71 °C
The HONEYWELL 2TL1-21 Micro Switch Toggle Switch is a high-quality and reliable component designed for various applications. Featuring a Double Pole Single Throw (DPST) configuration with a 2-position, half throw (Off-On) mechanism, this toggle switch ensures efficient control and operation. The switch is equipped with screw terminals, providing secure and convenient electrical connections. With a standard lever design and military part number MS24524-24, this toggle switch is built to military-grade specifications, ensuring durability and longevity. Trust HONEYWELL's TL Series Micro Switch Toggle Switches for superior performance and reliability in your applications.
Product Highlights:
  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
Potential Applications:
  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation
Search Keywords:
2TL121
IN STOCK: 163
Can Ship immediately
Factory Lead-Time
31 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$46.22
$46.220
5
$41.25
$206.250
10
$40.01
$400.100
25
$38.85
$971.250
50
$36.73
$1,836.500
100
$35.75
$3,575.000
250 +
$35.21
$8,802.500
