4TL1-2D by honeywell
DATA SHEET

4TL1-2D

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, 4 Pole Single Throw (4PST) 2 Position (Off - On), Screw Terminals, Locking Lever (Locked Out Of Center Position), Military Part Number MS24660-22D .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
4TL1-2D
Alias/AKA:
MS24660-22D
RoHS:
Yes
HTS:
8536509065
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Pole Throw Configuration:
4P1T (4PST)
Switch Configuration:
OFF None ON
Contact Rating @ Voltage:
745.7 A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.53 x 41.66 x 75.18 mm
Operating Temperature:
-65 to 71 °C
The HONEYWELL part 4TL1-2D is a high-quality MICRO SWITCH„¢ Toggle Switch from the TL Series. Designed with 4 poles, this switch has a single throw (4PST) with 2 positions (Off - On). It features screw terminals for easy and secure wiring connections. The switch is equipped with a locking lever that is locked out of the center position, providing added safety and preventing accidental operation. With a military part number MS24660-22D, this toggle switch is a reliable choice for various applications that require a durable and dependable electrical control.
Product Highlights:
  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
Potential Applications:
  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation
Search Keywords:
4TL12D
IN STOCK: 17
Can Ship immediately
On Order:
100   can ship 12/23/24
Factory Lead-Time
88 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$112.58
$112.580
5
$108.64
$543.200
10
$98.79
$987.900
25
$93.11
$2,327.750
50
$89.17
$4,458.500
100
$87.41
$8,741.000
250 +
$86.10
$21,525.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
