4TL1-5 by honeywell
DATA SHEET

4TL1-5

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, 4 Pole Double Throw (4PDT) 3 Position (Mom. On - Off - On), Screw Terminals, Standard Lever, Military Part Number MS24525-31 .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
4TL1-5
Alias/AKA:
MS24525-31
RoHS:
Yes
HTS:
85365080
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Pole Throw Configuration:
4P2T (4PDT)
Switch Configuration:
ON OFF (ON)
Contact Rating @ Voltage:
372.85 A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
33.5mm x 41.6mm x 63.47mm
Operating Temperature:
-65 to 71 °C
The HONEYWELL 4TL1-5 is a high-quality MICRO SWITCH Toggle Switch from the TL Series, featuring a 4 Pole Double Throw (4PDT) configuration with 3 position options (Momentary On - Off - On). This toggle switch is designed with screw terminals for easy and secure wire connections, and comes with a standard lever for reliable performance. It is military-grade and features the part number MS24525-31, ensuring durability and precision in demanding environments.
Product Highlights:
  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
Potential Applications:
  • Industrial machinery and equipment
  • Military and commercial aviation
  • Construction equipment
  • Test instruments
  • Agricultural machinery
  • Process control
  • Medical instrumentation
Search Keywords:
4TL15
IN STOCK: 31
Can Ship immediately
Factory Lead-Time
88 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$102.69
$102.690
5
$95.03
$475.150
10
$92.28
$922.800
25
$87.22
$2,180.500
50
$84.89
$4,244.500
100
$71.21
$7,121.000
250 +
$69.38
$17,345.000
