DATA SHEET

V7-1C13D8-201

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 5 A 125 Vac, 175g Maximum Operating Force, Short Roller Lever, UL Recognized, CSA, and VDE Certified, Quick Connect Termination .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-1C13D8-201
RoHS:
Yes
HTS:
85365009
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:
100
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Oil Bronze/Steel/Roller Lever
Contact Rating @ Voltage:
15.1@277VAC A
Maximum Movement Differential:
0.3 mm
Operating Force:
1.72 N
Termination Style:
Quick Connect
Dimension:
38.99 x 10.16 x 29.62 mm
Body Orientation:
Straight
IP Rating:
N/A

Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. V7 switches are used for simple or precision application needs. They are generally used in appliances, vending machines, timing devices, office equipment, computer and business equipment, test instruments, HVAC equipment, manually operated devices, gaming equipment, and pressure switches.

V7-1C13D8-201 Snap Action Switches from Honeywell is designed for 100K operations at a full load. This Honeywell Switch has a long mechanical life of up to 10M and is best suited for higher cost-of-failure applications.

Product Highlights:
  • World-wide package size acceptance
  • Current rating ranges from 0.1 A to 25 A
  • UL/CSA and ENEC approvals
  • Best suited for higher cost-of-failure applications
  • Designed for 100K operations at a full load or 10M for mechanical life
Search Keywords:
V71C13D8201
IN STOCK: 3,930
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
4 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$7.52
$37.600
25
$6.24
$156.000
50
$5.98
$299.000
100
$5.68
$568.000
300
$5.60
$1,680.000
500
$5.51
$2,755.000
1,000
$5.33
$5,330.000
2,500 +
$5.25
$13,125.000
