DATA SHEET

V7-7B19E9

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 11 A 125, 250, or 277 Vac, Pin Plunger, 227 g [8 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 6,35 mm x 0,81 mm [0.250 in x 0.032 in] Quick Connect Spread Termination, UL, CSA .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-7B19E9
RoHS:
Yes
HTS:
8536509055
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:
100
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Plastic/Plunger
Contact Rating @ Voltage:
11@277VAC A
Maximum Movement Differential:
0.25 mm
Operating Force:
2.22 N
Termination Style:
Quick Connect
Dimension:
39.37 x 10.16 x 23.72 mm
Body Orientation:
Straight
IP Rating:
N/A

Snap Action Switches, also known as micro switches are a kind of momentary contact switch. They are used for precision on/off, end of limit and manual operator interface application needs. These switches are used in appliances, vending machines, timing devices, office equipment, test instruments, medical and dental equipment, HVAC equipment, manually operated devices, and valves.

V7-7B19E9 Snap Action Switch from Honeywell is best suited for higher cost-of-failure applications and designed for operations at full load. With Single Pole Double Throw circuitry, the V7-7B19E9 Honeywell switch current rating ranges from 0.1 A to 25 A.

Product Highlights:
  • Best suited for higher cost-of-failure applications
  • Designed for 100K operations at a full load or 10M for mechanical life
  • World-wide package size acceptance
  • Current rating ranges from 0.1 A to 25 A
  • UL/CSA and ENEC approvals
Potential Applications:
  • Appliances
  • Vending machines
  • Timing devices
  • Office equipment
  • Computer/business equipment
  • Test instruments
  • Medical/dental equipment
  • Communications equipment
  • HVAC equipment
  • Manually operated devices
  • Valves
  • Gaming equipment
  • Pressure switches
Search Keywords:
V77B19E9
IN STOCK: 3,597
Can Ship immediately
Minimum Order:
10
Factory Lead-Time
23 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$5.30
$53.000
50
$3.92
$196.000
300
$3.08
$924.000
500
$3.03
$1,515.000
1,000
$2.99
$2,990.000
2,500
$2.94
$7,350.000
5,000
$2.90
$14,500.000
7,500 +
$2.86
$21,450.000
