7101MD9AQE by littelfuse/c-k
DATA SHEET

7101MD9AQE

Littelfuse/C&K

Miniature Toggle Switch - SP (On-None-On) - 5A@120VAC/2A@250VAC - .200" Actuator - 90° PCB Pin - 1/4-40 Bushing - Epoxy Seal .. see full description

RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
7101MD9AQE
RoHS:
Yes
HTS:
8536509040
COO:
VN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
Tray
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever
Mounting:
PC Mount with Bracket
Thread Size:
N/R
Body Orientation:
Right Angle
Terminal Type:
PC Pins
Dimension:
12.7 x 27.31 x 6.86 mm
Operating Temperature:
-30 to 85 °C
The C&K COMPONENTS part 7101MD9AQE is a versatile and reliable Miniature Toggle Switch. This compact switch is designed for easy integration into various electronic applications. With its compact size and durable construction, it offers excellent performance and long-lasting dependability. The 7101MD9AQE Miniature Toggle Switch is perfect for use in a wide range of industries, including automotive, telecommunications, industrial control, and consumer electronics. It is suitable for both low voltage and high voltage applications, making it a versatile choice for any project.
Search Keywords:
7101MD9AQE
IN STOCK: 3,635
Ships today, if you order in
Minimum Order:
5
Factory Lead-Time
16 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$8.38
$41.900
25
$6.26
$156.500
80
$6.10
$488.000
160
$5.91
$945.600
320
$5.80
$1,856.000
560
$5.74
$3,214.400
1,040
$5.68
$5,907.200
2,560 +
$5.62
$14,387.200
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
