7201MYZQE by littelfuse/c-k
DATA SHEET

7201MYZQE

Littelfuse/C&K

Miniature Toggle Switch - DP (On-None-On) - 5A@120VAC/2A@250VAC - .200" Actuator - Solder Lug - 1/4-40 Bushing - Epoxy Seal .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
7201MYZQE
RoHS:
Yes
HTS:
8536509040
COO:
VN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
12.7 x 11.43 x 26.8 mm
Operating Temperature:
-30 to 85 °C
Introducing the C&K COMPONENTS part 7201MYZQE, a high-quality miniature toggle switch designed for a variety of electronic applications. This DP (On-None-On) switch is rated for 5A at 120VAC and 2A at 250VAC, making it versatile and reliable for your needs. The switch features a .200" actuator, solder lug connections for easy installation, and a durable 1/4-40 bushing for added stability. Additionally, the switch is epoxy sealed for long-lasting protection against dust and moisture. Trust in C&K COMPONENTS for durable, high-performance switches like the 7201MYZQE for your electronic projects.
Search Keywords:
7201MYZQE
IN STOCK: 2
Ships today, if you order in
You may purchase in-stock quantity up to 2
On Order:
1,000   can ship 12/30/24
MOQ for In Stock Qty:
5
Available in less than min:
2
MOQ for out of Stock Qty:
25
Factory Lead-Time
10 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$14.674
$14.674
5
$13.340
$66.700
10
$11.710
$117.100
25
$10.990
$274.750
50
$10.880
$544.000
75
$10.770
$807.750
100 +
$9.060
$906.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
