TDA02H0SB1 by littelfuse/c-k
DATA SHEET

TDA02H0SB1

Littelfuse/C&K

Ultra-miniature Surface Mount Half-pitch DIP switch-SPST-sealed-0.025@24VDC A-2 positions .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
TDA02H0SB1
RoHS:
Yes
HTS:
8536509050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
125
Body Orientation:
Straight
Actuator Style:
Recessed Slide
Actuator Length:
0 mm
Number of Positions:
2
Pole Throw Configuration:
SPST
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.025@24VDC A
Contact Plating:
Gold/Nickel
Terminal Pitch:
1.27 mm
The TDA01H0SB1R with dimensions 6.21mm x 3.67mm x 2.3 mm has Surface Mount mounting with SPST Pole throw configuration ,SPST switching configuration and Recessed Slide actuator. The TDA01H0SB1R has operating force of 4.9 N and contact rating of 25mA@24V. This unsealed switch has Gull Wing termination style with Straight body orientation.It has bifurcated contact for increased electrical reliability and is process sealed for surface mount soldering and washable processing. C&K’s reliable TDA switches are found in hand-held electronic devices, portable computers and various forms of instrumentation and controls.
Search Keywords:
TDA02H0SB1
IN STOCK: 12,476
Ships today, if you order in
Minimum Order:
125
Multiple:
125
Factory Lead-Time
19 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
125
$1.61
$201.250
250
$1.48
$370.000
500
$1.41
$705.000
1,000
$1.37
$1,370.000
2,500
$1.34
$3,350.000
5,000
$1.32
$6,600.000
7,500
$1.30
$9,750.000
10,000 +
$1.28
$12,800.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
