GSM220A24-R7B by mean well
DATA SHEET

GSM220A24-R7B

Mean Well

AC/DC Adapter - Desktop - 221 Watts: 24V @ 9.2A - IEC 320-C14 Inlet - Medical .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
GSM220A24-R7B
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC
Type:
Regulated-Switching
Style:
Desktop Adapter
Output Type:
Fixed
Number of Outputs:
1
Power:
221 W
Output Voltage:
24 VDC
Output Current:
9.2 A
Ripple & Noise:
180 mV
Grade:
Medical
MOPP:
2X
DOE Efficiency Level:
VI
CoC Tier:
No
Safety Class:
II
Safety Approvals:
CB, CE, cRUus, TUV
Efficiency:
93.5(Typ) %
Output Connector Type:
DIN - Cyl - 4-Pin
Output Connector Polarity:
Not App
Output Connector Diameters:
Not App
Output Connector Angle:
Straight
Output Cord Length:
1.0m (39.4in)
AC Input Voltage:
80 to 264
Minimum AC Input Voltage:
80
Maximum AC Input Voltage:
264
Input Frequency:
47 to 63 Hz
Line Regulation:
1.00 %
Load Regulation:
3.00 %
Overload Protection:
Yes
Over Voltage Protection:
Yes
Short Circuit Protection:
No
Thermal Protection:
Yes
Operating Temperature:
-30 to 70 °C
Power Indicator:
Yes
Minimum Load (Amps):
0
Minimum Isolation Voltage:
4000 VAC
Input Connector Type:
IEC 320-C14
Dimensions L x W x H:
210.0 x 85.0 x 46.0 mm
Dimensions L x W x H(in):
8.27 x 3.35 x 1.82 in
The MEAN WELL part GSM220A24-R7B is a reliable and high-performance AC/DC adapter specifically designed for medical applications. With a power output of 221 Watts, it provides a stable and efficient power supply of 24V at 9.2A. Featuring a convenient desktop design, this adapter is user-friendly and easy to install. It is equipped with an IEC 320-C14 inlet, ensuring compatibility with standard power outlets. The GSM220A24-R7B meets strict medical safety standards, making it suitable for use in healthcare facilities. It offers excellent protection features such as overvoltage, overcurrent, and short-circuit protection, ensuring the safety of both the device and the user. With its robust construction and reliable performance, the MEAN WELL GSM220A24-R7B is the ideal AC/DC adapter for medical applications that require a dependable and efficient power supply.
