GST40A12-P1J by mean well
DATA SHEET

GST40A12-P1J

Mean Well

AC/DC High Reliability Industrial Desktop Adaptor - Output 12VDC at 3.34A - 3 pole AC inlet IEC320-C14 - 2.1mm Plug Level VI. .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
GST40A12-P1J
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC
Type:
Regulated-Switching
Style:
Desktop Adapter
Output Type:
Fixed
Number of Outputs:
1
Power:
40 W
Output Voltage:
12 VDC
Output Current:
3.34 A
Ripple & Noise:
150 mV
Grade:
Commercial
MOPP:
Not App
DOE Efficiency Level:
VI
CoC Tier:
No
Safety Class:
I
Safety Approvals:
BSMI, CB, CCC, CE, cUL, EAC, GS, PSE, RCM, TUV, UL
Efficiency:
89.5(Typ) %
Output Connector Type:
Barrel - Female
Output Connector Polarity:
Center Positive
Output Connector Diameters:
2.1x5.5 mm
Output Connector Angle:
Straight
Output Cord Length:
1.0m (39.4in)
AC Input Voltage:
90 to 264
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
264
Input Frequency:
47 to 63 Hz
Line Regulation:
1.00 %
Load Regulation:
3.00 %
Overload Protection:
Yes
Over Voltage Protection:
Yes
Short Circuit Protection:
No
Thermal Protection:
No
Operating Temperature:
-30 to 70 °C
Power Indicator:
Yes
Minimum Load (Amps):
0
Minimum Isolation Voltage:
3000 VAC
Input Connector Type:
IEC 320-C14
Dimensions L x W x H:
125.0 x 50.0 x 31.5 mm
Dimensions L x W x H(in):
4.93 x 1.97 x 1.24 in
GST40A12-P1J is single output 40W desktop adaptor with output voltage 12VDC at 3.34A. This class I desktop power supply features a very low No Load Power Consumption of ˂0.075W and up to 89.5% high efficiency, making it a good energy saving alternative. GST40A12-P1J comes in a 94V-0 rated plastic case, which is flame retardant and prevents users from electric shock. This desktop power adaptor complies with energy efficiency level VI. The power adapter features an LED indicator and protections for short circuit, overload and over voltage. The product guarantees safety and reliability and is ideal for applications such as consumer electronic devices, telecommunication devices, office facilities and industrial equipments. GST40A12-P1J has a 3 year factory warranty.
Search Keywords:
GST40A12P1J
IN STOCK: 386
Ships today, if you order in
Manufacturer Stock:
258   can ship 12/2/24
On Order:
520   can ship 12/26/24
Factory Lead-Time
16 Weeks can ship 3/7/25
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$17.30
$17.300
5
$16.50
$82.500
10
$15.70
$157.000
20 +
$15.30
$306.000
