HLG-150H-48B by mean well
DATA SHEET

HLG-150H-48B

Mean Well

AC/DC LED Power Supply – 48VDC - 153.6W-3.2A- Constant Current/Constant Voltage – Input from 90 to 305VAC – 3 in 1 dimming adjustable via potentiometer. .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
HLG-150H-48B
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Fixed, Dimmable
Dimming:
1 to 10 Vdc/PWM/Resistance
Maximum Output Power:
153 W
Output Voltage Range:
24.0 to 48.0 Vdc
Maximum Output Current:
3,200 mA (3.2 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 90 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, PSE, RCM, TUV
IEC Class:
None
SELV:
Yes
LPS:
No
Warranty:
7 Years
Family:
HLG-150H
The HLG-150H-48B is a 320W AC/DC LED driver featuring a dual mode constant voltage and constant current output. HLG-150H-48B operates from 90 to 305VAC. Voltage output is 48 VDC and constant output current region from 24-48VDC with rated current of 3.2A. Thanks to the high efficiency up to 94%,with the fanless design, it is able to operate from -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-150H-48B is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system. The HLG-150H-48B has a typical lifetime of 62000 hours and a 7-year factory warranty.
Search Keywords:
HLG150H48B
IN STOCK: 105
Can Ship immediately
Manufacturer Stock:
21   can ship 11/25/24
Factory Lead-Time
16 Weeks can ship 3/7/25
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$54.90
$54.900
5
$52.30
$261.500
10
$50.00
$500.000
20 +
$48.60
$972.000
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
