HLG-185H-36A by mean well
DATA SHEET

HLG-185H-36A

Mean Well

AC/DC LED Power Supply – 36VDC - 184.8W-5.2A- Constant Current/Constant Voltage – Input from 90 to 305VAC – No dimming function. .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
HLG-185H-36A
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Adjustable
Dimming:
No
Maximum Output Power:
187 W
Output Voltage Range:
18.0 to 36.0 Vdc
Maximum Output Current:
5,200 mA (5.2 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 90 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, PSE, RCM, TUV
IEC Class:
None
SELV:
Yes
LPS:
No
Warranty:
7 Years
Family:
HLG-185H
The HLG-185H-36A is a 185W AC/DC LED driver featuring a dual mode constant voltage and constant current output. HLG-185H-36A operates from 90 to 305VAC. Voltage output is adjustable from 33 to 40 VDC and current output adjustable from 2.6 to 5.2 A with rated current of 5.2A. Thanks to the high efficiency up to 94%,with the fanless design, it is able to operate from -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-185H-36A is equipped with various function options, such as built in potentiometer to adjust ouput current and voltage, so as to provide the optimal design flexibility for LED lighting system. The HLG-185H-36A has a typical lifetime of 62000 hours and a 7-year factory warranty.
Search Keywords:
HLG185H36A
IN STOCK: 171
Ships today, if you order in
Factory Lead-Time
16 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$57.40
$57.400
5
$54.70
$273.500
10
$52.20
$522.000
20 +
$50.70
$1,014.000
