HLG-320H-24B by mean well
DATA SHEET

HLG-320H-24B

Mean Well

AC/DC LED Power Supply – 24VDC - 320W-13.34A- Constant Current/Constant Voltage – Input from 90 to 305VAC – 3 in 1 dimming adjustable via potentiometer. .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
HLG-320H-24B
RoHS:
Yes
HTS:
8504409510
COO:
TW
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Fixed, Dimmable
Dimming:
1 to 10 Vdc/PWM/Resistance
Maximum Output Power:
320 W
Output Voltage Range:
12.0 to 24.0 Vdc
Maximum Output Current:
13,340 mA (13.34 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 90 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, PSE, RCM, TUV
IEC Class:
None
SELV:
Yes
LPS:
No
Warranty:
7 Years
Family:
HLG-320H
The HLG-320H-24B is a 320W AC/DC LED driver featuring a dual mode constant voltage and constant current output. HLG-320H-24B operates from 90 to 305VAC. Voltage output is 24 VDC and constant output current region from 12-24VDC with rated current of 13.34A. Thanks to the high efficiency up to 94%,with the fanless design, it is able to operate from -40℃ ~ +90℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-320H-24B is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system. The HLG-320H-24B has a typical lifetime of 62000 hours and a 7-year factory warranty.
Search Keywords:
HLG320H24B
IN STOCK: 176
Can Ship immediately
Manufacturer Stock:
301   can ship 11/25/24
Factory Lead-Time
16 Weeks can ship 3/6/25
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$99.40
$99.400
5
$94.70
$473.500
10
$90.50
$905.000
20 +
$87.90
$1,758.000
Please Note: Item may be subject to tariff fee if shipping within the United States
