HLG-600H-24A by mean well
DATA SHEET

HLG-600H-24A

Mean Well

AC/DC LED Pwr Sply - Const Volt - 600W - Adj: 24 Vdc @ 25,000mA (25.0 A) - Dim: No

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
HLG-600H-24A
RoHS:
Yes
HTS:
8504409510
COO:
TW
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC
Style:
Enclosed
Type:
Constant Voltage
Output Type:
Adjustable
Dimming:
No
Maximum Output Power:
600 W
Output Voltage Range:
20.4 to 25.2 VDC
Maximum Output Current:
25,000 mA (25.0 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 70 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, EAC, ENEC 17, PSE, RCM
IEC Class:
I
SELV:
Yes
LPS:
No
Warranty:
5 Years
Family:
HLG-600H
AC-DC Single output LED driver Mix mode (CV+CC) with built-in PFC; Output 24Vdc at 25A; IP65; Cable output; CC/CV adjustable with potentimeter. It has an output power of 600W.Width, height and depth is 144 mm, 48.5 mm, and 280 mm respectively.
Search Keywords:
HLG600H24A
IN STOCK: 519
Can Ship immediately
Manufacturer Stock:
201   can ship 11/18/24
Factory Lead-Time
16 Weeks can ship 2/26/25
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$205.20
$205.200
5
$195.50
$977.500
10
$186.80
$1,868.000
20 +
$181.40
$3,628.000
Please Note: Item may be subject to tariff fee if shipping within the United States
