SDR-240-48 by mean well
DATA SHEET

SDR-240-48

Mean Well

AC-DC Industrial DIN rail power supply; Output 48Vdc at 5A; Metal casing; Ultra slim width 63mm .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
SDR-240-48
RoHS:
Yes
HTS:
8504409530
COO:
TW
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Switching,Regulated
Style:
DIN Rail
AC Input Voltage:
88 to 264 V
Number of Outputs:
1
Output Voltage:
48 V
Maximum Output Current:
5 A
Maximum Output Power:
240 W
Input Connector Type:
Screw Clamp Terminal Block
Dimension:
63 x 113.5 x 125.2mm
The SDR-240-48 is a 240W Industrial DIN Rail Power Supply featuring Constant voltage mode output for single channel. SDR-240-48 input voltage ranges from 88 to 264VAC. Voltage output is 48VDC and adjustable from 48 to 55V and current output is adjustable from 0 to 5 A with rated current 5A. Thanks to the high efficiency up to 94%, it is able of operating from -25 to +70 ℃ case temperature under free air convection. SDR-240-48 uses built-in active PFC function with power factor PF>.93. The SDR-240-48 has a 3 years factory warranty.
Search Keywords:
SDR24048
IN STOCK: 409
Can Ship immediately
Manufacturer Stock:
128   can ship 12/6/24
Factory Lead-Time
16 Weeks can ship 3/13/25
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$94.20
$94.200
5
$89.80
$449.000
10
$85.80
$858.000
20 +
$83.30
$1,666.000
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
