MCP1700T-3302E/TT by microchip technology
DATA SHEET

MCP1700T-3302E/TT

Microchip Technology

Fixed LDO Voltage Regulator - 2.3V to 6V - 178mV Dropout - 3.3Vout - 250mAout. .. see full description

  • RoHS Compliant
  • REEL Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP1700T-3302E/TT
RoHS:
Yes
HTS:
8542390060
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:
3000
Package Type:
REEL
Function:
LDO
Junction to Ambient:
336(Typ) °C/W
Family:
MCP1700
Accuracy:
±2 %
Dimension:
2.9 x 1.3 x 0.95 mm
Maximum Input Voltage:
6 V
Junction to Case:
N/A
Maximum Dropout Voltage @ Current:
0.35@250mA V
Load Regulation:
1(Typ) %
Line Regulation:
0.75(Typ) %/V
The MCP1700 is a CMOS low dropout positive voltage regulator which can source up to 250mA of current with an extremely low input-output voltage differential of 178mV at 250mA. The low dropout voltage combined with the low current consumption of only 1.6µA makes this part ideal for battery operation. The low voltage differential (dropout voltage) extends battery operating lifetime. The MCP1700 is stable with 1.0µF ceramic output capacitor. It also permits high currents in small packages when operated with minimum VIN – VOUT differentials. The circuit also incorporates short-circuit protection & over temperature protection to ensure maximum reliability.
