MIC5209-3.3YM-TR by microchip technology
DATA SHEET

MIC5209-3.3YM-TR

Microchip Technology

500 mA Low-Noise LDO Regulator - 3.3V - -40°C-125°C - 8LD SOIC Package .. see full description

RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MIC5209-3.3YM-TR
RoHS:
Yes
HTS:
8542390060
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2500
Package Type:
REEL
Dimension:
4.93 x 3.94 x 1.48 mm
Accuracy:
±1 %
Maximum Input Voltage:
16 V
Junction to Ambient:
50 °C/W
Family:
MIC5209
Function:
LDO
Junction to Case:
20 °C/W
Maximum Dropout Voltage @ Current:
0.06@100uA,0.175@50mA,0.3@150mA,0.5@500mA V
Load Regulation:
0.5 %
Line Regulation:
0.05 %/V
The MIC5209-3.3YM-TR is an efficient linear voltage regulator with very low dropout voltage, typically 10 mV at light loads and less than 500 mV at full load, with better than 1% output voltage accuracy. Output voltage is 3.3V. Operating temp. is -40°C-125°C. Package type is 8-lead SOIC.
Search Keywords:
MIC520933YMTR
  Different packaging options available.  See Alternatives
IN STOCK: 4,000
Ships today, if you order in
Manufacturer Stock:
2,500   can ship 12/2/24
Minimum Order:
250
Factory Lead-Time
7 Weeks can ship 1/10/25
Enter Quantity
Quantity
Unit Price
Ext. Price
250
$1.029
$257.250
500
$1.019
$509.500
1,000
$1.009
$1,009.000
2,500
$0.999
$2,497.500
5,000
$0.989
$4,945.000
7,500
$0.979
$7,342.500
10,000 +
$0.969
$9,690.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
