MIC5209-3.3YS-TR by microchip technology
DATA SHEET

MIC5209-3.3YS-TR

Microchip Technology

Fixed LDO Voltage Regulator - 2.5 V to 16 V in - 350 mV Dropout - 3.3 Vout - 500 mA out - SOT-23-3 - 4-Pin(3+Tab). .. see full description

RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MIC5209-3.3YS-TR
RoHS:
Yes
HTS:
8542390060
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2500
Package Type:
REEL
Dimension:
6.5 x 3.5 x 1.6 mm
Line Regulation:
0.05 %
Maximum Dropout Voltage @ Current:
0.06@100uA,0.175@50mA,0.3@150mA,0.5@500mA V
Junction to Ambient:
50 °C/W
Function:
LDO
Family:
MIC5209
Load Regulation:
0.5 %
Junction to Case:
8 °C/W
Accuracy:
±1 %
Maximum Input Voltage:
16 V
The MIC5209-3.3YS TR is a 500mA 3.3V low-Noise LDO Regulator with very low dropout voltage, typically 10mV at light loads and less than 500mV at full load with better than 1% output voltage accuracy. Designed especially for hand-held, battery-powered devices, the regulator features low ground current to help prolong battery life.
Search Keywords:
MIC520933YSTR
  Different packaging options available.  See Alternatives
IN STOCK: 13,987
Can Ship immediately
Manufacturer Stock:
130,000   can ship 11/29/24
Minimum Order:
250
Factory Lead-Time
8 Weeks can ship 1/9/25
Enter Quantity
Quantity
Unit Price
Ext. Price
250
$1.196
$299.000
500
$1.184
$592.000
1,000
$1.172
$1,172.000
2,500
$1.161
$2,902.500
5,000
$1.149
$5,745.000
7,500
$1.138
$8,535.000
10,000 +
$1.126
$11,260.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
