PIC16F76-I/SP

PIC 16 microcontroller - MCU 8 bit - RISC architecture - 2 V to 5.5 V - Pins: 28 - Package type: SPDIP 28 – Speed 20MHz - Flash 8192 words – SRAM 368 Bytes – I/O: 22 – A/D: 8 bits with 05 channels – 2x CCP PWM – 03 Timers – USART - SSP - I2C - SPI - 2,200 .. see full description

RoHS Compliant

TUBE Packaging

Request Programming Quote

Certificate of Compliance Guarantee

Product Attribute

Attribute Value Select Attribute

Products found: 0

Supplier:

Microchip Technology

Part No:

PIC16F76-I/SP

RoHS:

Yes

HTS:

8542310015

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

Package Type:

TUBE

Operating Temperature:

-40 to 85 °C

RAM Size:

368 B

ADC Resolution:

8 bit

Program Memory Size:

14 KB

Program Memory Type:

Flash

Number of Programmable I/Os:

The MICROCHIP TECH PIC16F76-I/SP is part of PIC16F mid-range family with a 8-Bit RISC microcontroller. It can sustain standard temperature ranges from -40°C to +85°C, has 28 pin in SPDIP 28 package and 20 MHz clock speed. This device has a Flash memory of 8192 words, a RAM of 368 bytes, three timers and two CCP module and 05 channels of 08 bits ADC. This MCU includes SSP & USART communication modules (I2C & SPI modules) with 22 I/O pins. It can be used to achieve various tasks.
