NC3FAAH1 by neutrik
DATA SHEET

NC3FAAH1

Neutrik

AA Series - 3 pole female XLR receptacle - grounding: mating connector shell to pin1 and front panel - horizontal PCB mount Most cost-effective round plastic body XLR PCB mount panel connector. Front panel cutout and PCB layout 100% compatible to A seri .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Neutrik
Part No:
NC3FAAH1
RoHS:
Yes
HTS:
8536694040
COO:
LI
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
IP40 XLR Connector
Gender:
RCP
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide 6/6
Number of Contacts:
3
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C
New most cost-effective round plastic body XLR PCB mount panel connector. Front panel cutout and PCB layout 100% compatible to A series. New "tulip" type contact design with high contact pressure for highest durability. Push latch assembled. Flammability rating UL94HB.

3 pole female XLR receptacle, grounding: mating connector shell to pin1 and front panel, horizontal PCB mount
Product Highlights:
  • Most cost-effective series
  • "Tulip" type contact design with high contact pressure for highest durability
  • Selective gold plated contact and PCB termination area for best conductivity and solderability
Search Keywords:
NC3FAAH1
IN STOCK: 1,000
Ships today, if you order in
Manufacturer Stock:
4,600   can ship 11/29/24
Minimum Order:
100
Multiple:
100
Factory Lead-Time
3 Weeks can ship 12/6/24
Enter Quantity
Quantity
Unit Price
Ext. Price
100
$1.210
$121.000
300
$1.172
$351.600
500
$1.119
$559.500
1,000
$1.071
$1,071.000
2,500
$1.027
$2,567.500
5,000
$1.000
$5,000.000
7,500
$0.985
$7,387.500
10,000 +
$0.970
$9,700.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
