NC5FAH by neutrik
DATA SHEET

NC5FAH

Neutrik

A Series - 5 pole female XLR receptacle - grounding: separate ground contact to mating connector shell and front panel - horizontal PCB mount The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest si .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Neutrik
Part No:
NC5FAH
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
F
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide 6/6
Number of Contacts:
5
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C
The NC5FAH is 5 pole female XLR receptacle, grounding: separate ground contact to mating connector shell and front panel, horizontal PCB mount The NC5FAH has rated voltage of < 50 V and rated current per contact of 3 A and dielectric strength of 1,5 kVdc . The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23 mm between centres). New designed tulip type contacts with gold plating of contact area and tin plated pcb termination area.
Product Highlights:
  • Smallest XLR receptacles, highest packing density
  • Plastic housing, steel latch lock
  • Fork type female contact
  • Polished contact areas and hard gold plating
  • Housing flammability UL94HB
Search Keywords:
NC5FAH
IN STOCK: 1,788
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
3 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$5.72
$28.600
50
$4.98
$249.000
100
$4.27
$427.000
300
$4.21
$1,263.000
500
$4.15
$2,075.000
1,000
$4.08
$4,080.000
2,500
$4.02
$10,050.000
5,000 +
$3.96
$19,800.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
