NHD-0224BZ1-FSW-FBW by newhaven display
DATA SHEET

NHD-0224BZ1-FSW-FBW

Newhaven Display

LCD Character Display - 2 x 24 Characters - 5V - 8-Bit Parallel - Controller:KS0066U - 2x8 Left .. see full description

RoHS Compliant
Bulk Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-0224BZ1-FSW-FBW
RoHS:
Yes
HTS:
8531200020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Display Format:
2 x 24 Characters
Display Type:
FSTN (+)
Display Mode:
Transflective
Text Color:
Black
Background Color:
White
Backlight:
LED - White
Active Area:
76.3 x 11.6 mm
Character Size:
5.55 x 2.70 mm
Dimension:
116 x 37 mm
Interface:
8-Bit Parallel
Supply Voltage:
5 V
Operating Temperature:
-20 to +70 °C
The NHD-0224BZ1-FSW-FBW is a 2 x 24 Character LCD Character Display. It features a FSTN (+) Transflective Display with a White- High Brightness Backlight. Character size is 5.55 x 2.70 mm. It uses an 8-Bit Parallel Interface. Voltage requirement is 5V. Controller required is the KS0066U
Search Keywords:
NHD0224BZ1FSWFBW
IN STOCK: 45
Ships today, if you order in
Manufacturer Stock:
267   can ship 11/29/24
Minimum Order:
5
Factory Lead-Time
15 Weeks can ship 2/28/25
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$15.68
$78.400
25
$14.93
$373.250
50
$14.03
$701.500
100
$13.35
$1,335.000
250
$12.68
$3,170.000
500
$12.18
$6,090.000
1,000 +
$11.99
$11,990.000
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
