NHD-0420H1Z-FSW-GBW by newhaven display
DATA SHEET

NHD-0420H1Z-FSW-GBW

Newhaven Display

LCD Character Display - 4 x 20 Character - STN- Gray - White Backlight - 79.0 x 36.0 mm .. see full description

RoHS Compliant
Bulk Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-0420H1Z-FSW-GBW
RoHS:
Yes
HTS:
8531200020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bulk
Display Format:
4 x 20 Characters
Display Type:
STN- GRAY
Display Mode:
Transflective
Text Color:
Blue
Background Color:
White
Backlight:
LED - White
Active Area:
56.5 x 23.6 mm
Character Size:
5.15 x 2.35 mm
Dimension:
79 x 36 x 13 mm
Interface:
8-Bit Parallel
Supply Voltage:
5 V
Operating Temperature:
-20 to +70 °C
The NHD-0420H1Z-FSW-GBW is a 4 x 20 Character LCD Character Display. It features a STN- Gray Transflective Display with a White Backlight. Character size is 5.15 x 2.35 mm. It uses an 8-Bit Parallel Interface. Voltage requirement is 5V. Controller required is the SPLC780D or ST7066U
Search Keywords:
NHD0420H1ZFSWGBW
IN STOCK: 577
Can Ship immediately
Manufacturer Stock:
613   can ship 12/6/24
Factory Lead-Time
15 Weeks can ship 3/6/25
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$23.03
$23.030
10
$18.16
$181.600
25
$17.88
$447.000
50
$16.92
$846.000
100
$15.70
$1,570.000
250
$15.18
$3,795.000
500 +
$14.39
$7,195.000
Tools/3D Models
Request Free CAD Models
