DATA SHEET

A6RS-162RF-P

Omron Electronics

Switch DIP N.O./N.C. SP16T 16 Flush Screwdriver 0.025A 24VDC Gull Wing 2.54mm SMD T/R .. see full description

RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
A6RS-162RF-P
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
750
Package Type:
Reel
Body Orientation:
Straight
Actuator Style:
Flush Screwdriver
Actuator Length:
0 mm
Number of Positions:
16
Pole Throw Configuration:
SP16T
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.025@24VDC A
Contact Plating:
N/A
Terminal Pitch:
2.54 mm
The OMRON ELECTRONICS part A6RS-162RF-P is a versatile and reliable DIP switch designed for various electronic applications. With its 16 poles, it allows for easy switching between Normally Open (N.O.) and Normally Closed (N.C.) configurations. The switch features a SP16T (Single Pole 16 Throw) design, providing multiple options for signal routing. Featuring a flush screwdriver actuator, this DIP switch is convenient to use and ensures precise and effortless switching. It has a low current rating of 0.025A and a voltage rating of 24VDC, making it suitable for low-power applications. The switch is surface mountable with a Gull Wing configuration, allowing for easy integration into PCB designs. It features a pin pitch of 2.54mm, ensuring compatibility with common SMD mounting standards. Supplied in tape and reel packaging (T/R), the A6RS-162RF-P is optimized for automated assembly processes. It is a high-quality and durable component, offered by OMRON ELECTRONICS, a renowned manufacturer of electronic components trusted worldwide.
Search Keywords:
A6RS162RFP
IN STOCK: 300
Ships today, if you order in
On Order:
1,500   can ship 4/2/25
Minimum Order:
100
Factory Lead-Time
26 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
100
$2.79
$279.000
250
$2.47
$617.500
750
$2.35
$1,762.500
1,500
$2.32
$3,480.000
3,000
$2.28
$6,840.000
5,250
$2.25
$11,812.500
7,500
$2.21
$16,575.000
10,500 +
$2.18
$22,890.000
Please Note: Item may be subject to tariff fee if shipping within the United States
