D3V-16G2-1C25-K by omron electronics
DATA SHEET

D3V-16G2-1C25-K

Omron Electronics

Switch Snap Action N.O./N.C. SPDT Hinge Lever Quick Connect 16A 250VAC 250VDC 372.85VA 1.23N Screw Mount .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
D3V-16G2-1C25-K
RoHS:
Yes
HTS:
8536509040
COO:
ID
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Stainless Steel/Hinge Lever
Contact Rating @ Voltage:
372.85@(CSA/UL) A
Maximum Movement Differential:
0.8 mm
Operating Force:
1.23 N
Termination Style:
Quick Connect
Dimension:
48.4 x 10.3 x 24.9 mm
Body Orientation:
Straight
IP Rating:
IP40
The OMRON ELECTRONICS part D3V-16G2-1C25-K is a reliable and versatile snap action switch. It offers a single-pole double-throw (SPDT) configuration with a hinge lever for quick and easy connection. With a maximum current rating of 16A and voltage rating of 250VAC and 250VDC, this switch is suitable for a wide range of applications. It has a high power rating of 372.85VA and a low operating force of 1.23N, ensuring efficient and effortless operation. The switch is designed for convenient screw mounting, making it easy to install in various electrical systems.
Search Keywords:
D3V16G21C25K
IN STOCK: 465
Ships today, if you order in
Manufacturer Stock:
57,200   can ship 11/29/24
Minimum Order:
10
Factory Lead-Time
4 Weeks can ship 12/13/24
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$2.19
$21.900
100
$1.42
$142.000
300
$1.40
$420.000
500
$1.38
$690.000
1,000
$1.35
$1,350.000
2,500
$1.33
$3,325.000
5,000
$1.31
$6,550.000
7,500 +
$1.29
$9,675.000
