G2R-1-E-DC24 by omron electronics
DATA SHEET

G2R-1-E-DC24

Omron Electronics

Power Relay 24VDC 16A SPDT(29x13x25.5)mm THT .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued & Replaced
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G2R-1-E-DC24
Alias/AKA:
G2R1EDC24BYOMI,
RoHS:
Yes
HTS:
8536490050
COO:
ID
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPDT10703
Maximum Current Rating:
16 A
Mounting:
Through Hole10716
Termination Style:
PC Pin10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-40 to 70 °C
Coil Resistance:
1.1 KOhm
Life Cycle:
Discontinued & Replaced
The G2R-1-E-DC24 is a 1-pole Power PCB Relay with DC coil, G2R series. 1CO (SPDT) contact configuration, high capacity classification. 8mm/8mm clearance and creepage distance, PCB terminal. Safety-oriented design with dielectric strength of 5000V between coil and contacts and surge resistance of 10000V. Meets VDE0700 requirements for household products according to VDE0110. Conforms to VDE0435 (VDE approval, C250 insulation grade), UL508, CSA22.2, SEV, SEMKO. Operating Temperature -40°C ~ 70°C Single-side stable relay Flux protection enclosure Applications Industrial, Power Management, Automation & Process Control
Search Keywords:
G2R1EDC24
  This product is discontinued, but still in stock
IN STOCK: 435
Can Ship immediately
On Order:
2,000   can ship 1/29/25
Minimum Order:
5
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$5.78
$28.900
50
$3.69
$184.500
100
$3.58
$358.000
300
$3.52
$1,056.000
500
$3.47
$1,735.000
1,000
$3.42
$3,420.000
2,500
$3.34
$8,350.000
5,000 +
$3.29
$16,450.000
Suppliers Standard Package
RECOMMENDED REPLACEMENT
G2R1EDC24BYOMI
G2R1EDC24BYOMI
VIEW PRODUCT
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
