G6B-1174P-US-DC24 by omron electronics
DATA SHEET

G6B-1174P-US-DC24

Omron Electronics

Power Relay 24VDC 8A SPST-NO(21.1x10x12.5)mm THT .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6B-1174P-US-DC24
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
400
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO10703
Maximum Current Rating:
8 A
Mounting:
Through Hole10716
Termination Style:
PC Pin10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-25 to 70 °C
Coil Resistance:
2.88 KOhm
The G6B-1174P-US-DC24 is a PCB mount Power Relay with DC coil. This G6B-series power relay has 1NO (SPST) cadmium-free Ag alloy contact. High capacity classification and PCB terminals and mounted directly to PCB. High sensitive with operating power of 98mW. High insulation with dielectric strength of 3000VAC between coil and contacts (impulse withstand voltage of 6kV). Stick packing models are provided in consideration of compatibility to the automatic production line. Single side stable function Fully sealed enclosure Standard washability -25 to 70°C Operating temperature range Applications Industrial, Automation & Process Control
Search Keywords:
G6B1174PUSDC24
IN STOCK: 2,451
Ships today, if you order in
Manufacturer Stock:
3,600   can ship 12/2/24
Minimum Order:
5
Factory Lead-Time
4 Weeks can ship 12/13/24
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$6.60
$33.000
25
$4.93
$123.250
50
$4.73
$236.500
100
$4.43
$443.000
400
$4.31
$1,724.000
800
$4.25
$3,400.000
1,200
$4.18
$5,016.000
2,800 +
$4.12
$11,536.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
