G6K-2F-DC5 by omron electronics
DATA SHEET

G6K-2F-DC5

Omron Electronics

Signal Relay 5VDC 1A DPDT(10x7.8x5.2)mm SMD .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6K-2F-DC5
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Tube
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
2 A
Mounting:
Surface Mount12526
Operating Temperature:
-40 to 70 °C
Dimension:
10 x 6.5 x 5.2 mm
Termination Style:
Gull Wing12536
Coil Current:
21.1 mA
Contact Form:
2 Form C12515
The G6K-2F-DC5 is a 2-pole Surface-mount Relay with DC coil, G6K series. DPDT (2CO) contact configuration, outside-L surface mounting terminals. Subminiature model as small as 5.2 (H) x 6.5 (W) x 10mm (L) is ideal for high-density mounting. Low profile of 5.2mm improves mounting efficiency. Lightweight of 0.7g contributes to higher speed mounting. Consumes approximately 70% the power of a conventional OMRON model and operates at a current that is as low as 100mW. Surface mounting terminal models incorporate an unique terminal structure with high infrared irradiation efficiency which allows the terminal temperature to rise easily when mounting the IRS, thus ensuring excellent soldering. Single-side stable relay Fully sealed enclosure Applications Industrial, Power Management, Automation & Process Control, Consumer Electronics, Security, Test & Measurement, Communications & Networking
Search Keywords:
G6K2FDC5
  Different packaging options available.  See Alternatives
IN STOCK: 3,135
Can Ship immediately
Manufacturer Stock:
9,000   can ship 11/29/24
Minimum Order:
10
Factory Lead-Time
4 Weeks can ship 12/12/24
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$3.50
$35.000
50
$2.82
$141.000
250
$2.49
$622.500
500
$2.44
$1,220.000
1,000
$2.39
$2,390.000
2,500
$2.34
$5,850.000
5,000
$2.31
$11,550.000
7,500 +
$2.27
$17,025.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
