DATA SHEET

G6K-2F-RF-TR09-DC5

Omron Electronics

Electromechanical Relay 5VDC 237Ohm 1A DPDT (12.8x7.8x5.4)mm SMD High Frequency Relay .. see full description

RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6K-2F-RF-TR09-DC5
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
900
Package Type:
Reel
Relay Construction:
Non-Latching
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Surface Mount
Pin Count:
8
Operating Temperature:
-40 to 70 °C
Dimension:
12.8 x 7.8 x 5.4 mm
Termination Style:
Gull Wing
The Omron G6K-2F-RF-TR09-DC5 is a compact and high-performance electromechanical relay designed for high-frequency applications. With a supply voltage of 5VDC, this relay offers a low power consumption while providing reliable switching capabilities.Featuring a double-pole double-throw (DPDT) configuration, this relay can handle a maximum current of 1A, making it suitable for various electronic circuits and control systems. Its low coil resistance of 237 Ohm ensures efficient power transfer and helps maintain signal integrity.Measuring just 12.8x7.8x5.4mm in size, this relay is surface-mountable, making it easy to integrate into compact designs with limited space. Its small form factor and SMD packaging allow for high-density placement on PCBs, saving valuable board space.The G6K-2F-RF-TR09-DC5 is specifically designed for high-frequency applications, enabling seamless operation in systems that require fast and precise switch control. It offers excellent electrical characteristics, including low insertion loss and high isolation, ensuring reliable signal transmission in RF and microwave applications.Overall, the Omron G6K-2F-RF-TR09-DC5 is an ideal electromechanical relay for high-frequency applications where compact size, low power consumption, and reliable switching are vital. Its versatility and exceptional performance make it a preferred choice for various industries, including telecommunications, automotive, industrial automation, and more.
Search Keywords:
G6K2FRFTR09DC5
  Different packaging options available.  See Alternatives
  Possible Replacement options available.  See Alternatives
IN STOCK: 546
Ships today, if you order in
MOQ for out of Stock Qty:
225
Factory Lead-Time
26 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$28.92
$28.920
50
$18.28
$914.000
100
$17.72
$1,772.000
225
$17.54
$3,946.500
450
$17.37
$7,816.500
675
$17.20
$11,610.000
900 +
$17.02
$15,318.000
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
